This course is developed for engineers and technicians who need to have a practical knowledge of selection, installation and commissioning of fiscal metering equipment. It is for those primarily involved in achieving effective results in industrial processes. This would involve the design, specification and implementation of control and measurement equipment. The course focuses on practical applications, with special attention to installation considerations and application limitations when selecting or installing different measurement or control instruments for fiscal metering.
OUTLINE MATERI
1. Basic Fluid Flow:
a) Fluid property
* Density
* Viscosity
* Surface tension
* Modulus elasticity
b) Compressible & Incompressible flow
c) Fluid Flow
* Continuity Equation
* Bernoulli Equation
d) Pipe fluid flow
e) Fluid Flow Measurement
2. Performance Characteristic of Flowmeter
* Accuracy
* Repeatability
* Performance Measure
* Calculation
3. Head Flow Meter
* Orifice
* Sizing
* Secondary Instrument
* Calculation
* Standard AGA3
4. Turbine Meter
* Systems
* Properties
* Characteristics
* Standard AGA7
5. Ultrasonic Flowmeter
* Ultrasonic Flowmeter
* Types
* Application
* Standard AGA9
6. Oil Transfer Meter:
* Meter Run
* Proving Skid
* Meter Proving
* Meter Factor
* Base Prover
* Proving Run
* Prover Pass
* Prover Round Trip
* Proving Counter
7. Shipping Calculate Volume & Calculate Correction:
* Temperature material
* Pressure material
* Oil Temperature
* Oil Pressure
* Sediments and water
* Calculate Meter Factor
8. Retroactive Meter Factor
* Manual retroactive factor
9. Calculation Sample:
* Flow calculation
* Oil Quantity measurement
10. Use Measurement Systems in MIGAS Activities
WHO SHOULD ATTEND ?
* Instrumentation Engineers & technicians
* Design & Process Engineers
* Operation Engineer
* Well testing group
* Production Operation
* Reservoir Engineering & technicians
* Maintenance Superintendent & Supervisor
METHOD
Presentation
Discussion
Case Study
Evaluation
Instructor by : Bambang Murcahyanto
